Kingfisher Spare Parts

Item#	Part Details	Availability	£
Drawing 1
A	20098893 PULL-START ASSEMBLY	Not Available
1	20054552 SCREW - M5X20	Not Available
2	GB/T93 SPLIT WASHER - M5	Not Available
3	20054561 WASHER	Not Available
4	20060079 LOGO PLATE $$$	Not Available
5	20081531 PULL-START HOUSING $$$	Not Available
6	20054579 EYELET $$$	Low Stock	5.02
7	20056239 START ROPE $$$	Low Stock	5.69
8	20081175 STARTER HANDLE $$$	In Stock	3.99
9	20057230 COIL SPRING $$$	Low Stock	15.50
10	20057231 COIL SPRING COVER $$$	Low Stock	5.38
11	20060014 START PULLEY $$$	Low Stock	9.29
12	20060010 START THE TORSIONAL SPRING $$$	Low Stock	5.78
13	20060009 START THE RATCHET $$$	Low Stock	6.29
14	20060011 START THE DIALCLAW $$$	Low Stock	4.99
15	20062782 PLATE WASHER $$$	Not Available
16	20060012 CIRCLIP $$$	Not Available
17	20060085 AIR DEFLECTOR	Not Available
18	20054543 SCREW $$$	Not Available
19	20081533 MUFFLER COVER	Not Available
20	20054543 SCREW $$$	Not Available
21	20071547 SEALING RUBBER	Low Stock	5.69
22	20054557 NUT - M8	Not Available
23	20051407 MAGNETO ROTOR	Low Stock	Contact Us
24	20056600 OIL SEAL	In Stock	3.99
25	20061125 SCREW M5X35	Not Available
26	GB/T93 SPLIT WASHER - M5	Not Available
27	20054561 WASHER	Not Available
28	20071542 REAR HALF CRANKCASE	Not Available
29	20051405 GASKET CRANK CASE	Not Available
30	20061605 BEARING 6201	Not Available
31	20071544 CRANK SHAFT ASS'Y	Low Stock	19.04
32	GB/T1099 SEMICIRCULAR KEY 33.510	Not Available
33	B23.0103.0300 PIN SCREW 8X11X10	Not Available
34	A36.0103.0003 GUDGEON PIN CLIP	On Order	Contact Us
35	20054461 PISTON PIN	On Order	5.33
36	20054462 PISTON	On Order	10.14
37	20054460 PISTON RING	On Order	6.14
38	20051404 GASKET CYLINDER	On Order	5.69
39	20061605 BEARING 6201	Not Available
40	01.05.0161 PIN - 3X9MM	Not Available
41	20071543 FRONT HALF CRANKCASE	Not Available
42	20056600 OIL SEAL	In Stock	3.99
43	01.01.1721 SCREW - M4X20 $$$	In Stock	5.18
44	GB/T93 SPLIT WASHER - M5	Not Available
45	GB/T97.1 PLATE WASHER 5	Not Available
46	20051408 IGNITION	Low Stock	22.60
47	F28.0106.0201 SPARK PLUG COVER	Not Available
48	20060003 WIRE CABLE	Not Available
49	20060887 SCREW M5X60	Not Available
50	01.04.0091 LOCK WASHER 5	Not Available
51	20054561 WASHER	Not Available
52	20060002 MUFFLER INSULATION COVER	Not Available
53	20071546 MUFFLER	Low Stock	27.05
54	20051403 MUFFLER GASKET	Low Stock	5.47
55	20050781 SPARK PLUG - NGK BPMR7A	In Stock	9.99
56	20061082 SCREW - M5X25	Not Available
57	GB/T93 SPLIT WASHER - M5	Not Available
58	GB/T97.1 PLATE WASHER 5	Not Available
59	20071540 CYLINDER	On Order	28.39
60	20051402 INLET PIPE SEALING GASKET	Not Available
61	20071541 ADMITTING PIPE	Not Available
62	20054561 WASHER	Not Available
63	GB/T93 SPLIT WASHER - M5	Not Available
64	20054552 SCREW - M5X20	Not Available
65	20050971 CARBURETTOR GASKET	Not Available
66-A	20082539 CARBURETTOR - WALBRO (WT-1256)	Low Stock	24.99
66-B	20092910 CARBURETTOR - RUIXING (MC1370BE)	Not Available
67	20068625 AIR DOOR KONB	Not Available
69	20060005 AIR BOX BASE	Not Available
70	GB/T97.1 PLATE WASHER 5	Not Available
71	GB/T93 SPLIT WASHER - M5	Not Available
72	20061126 SCREW M5X45	Not Available
73	20060004 SPONE	Not Available
74	20081532 AIR BOX COVER	Not Available
75	20079925 AIR FILTER KONB	Low Stock	5.47
76	20054536 SCREW $$$	Not Available
77	20060978 SCREW $$$	Not Available
78	20081530 LOWER HANDLE UPPER COVER	Low Stock	8.36
79	20081525 LOWER HANDLE	Low Stock	17.26
80	20081527 LOWER HANDLE LOWER COVER	Low Stock	8.36
81	20081528 LOWER HANDLE SUPPORT	Low Stock	10.14
82	20060061 THROTTLE SETTING KNOB	Low Stock	5.51
83	20081539 UPPER HANDLE LEFT SOFT COVER	Low Stock	9.25
84	20081536 UPPER HANDLE LEFT COVER	Low Stock	11.92
85	20081537+20068723 UPPER HANDLE RIGHT COVER	Low Stock	30.62
86	20068726 DRIVING LEVER	Low Stock	5.69
87	20060059 REED	Not Available
88	20054536 SCREW $$$	Not Available
89	20060050 TRIGGER	Low Stock	5.25
90	20060058 THE THROTTLE CONNECT ROD	Low Stock	6.58
91	20054576 FUEL TANK ASSEMBLY - BREATHER TUBE	Not Available
92	20054685 FUEL TANK BREATHER VALVE	Low Stock	3.99
93	20054576 FUEL TANK ASSEMBLY - BREATHER TUBE	Not Available
94	20070348 FUEL TUBE BASE	Not Available
95	B23.0111.0002 FUEL PIPE 2.5X5X230	Low Stock	5.05
96	20054663 FUEL TANK ASSEMBLY - PIPE CLIP	Not Available
97	20053113 FUEL FILTER	Low Stock	7.47
98	20054582 CAP RETAINER $$$	Not Available
99	20054574 O-RINGS	Not Available
100	20057031 FUEL TANK CAP	Low Stock	7.03
101	20068666 FIXED BLOCK	Not Available
102	20060015 DAMPING SPRING	Low Stock	9.73
103	20051414 OFF LINE	Not Available
104	02.05.86 SWITCH	In Stock	4.99
105	E58.0152.0005 SWITCH COVER	Low Stock	3.99
106	20060978 SCREW $$$	Not Available
107	20081542 VOLRTE(LEFT)	Low Stock	20.38
108	20061082 SCREW - M5X25	Not Available
109	GB/T97.1 PLATE WASHER 5	Not Available
110	GB/T93 SPLIT WASHER - M5	Not Available
111	20081524 UPPER HANDLE LEFT SOFT COVER	Low Stock	8.36
112	20059487 SPRING	In Stock	5.51
113	20060019 FIXED LINK	Not Available
114	20060039 SEALING	Not Available
115	20060037 WAHSER	Low Stock	9.25
116	20060036 WORM WHEEL	Not Available
118	20061395 LEFT HANDED NUTM8	Not Available
119	20051412 SIDE SAFETY SWITCH	Low Stock	6.22
120	20081538 VOLRTE(RIGHT)	Low Stock	23.05
121	20051412 SIDE SAFETY SWITCH	Low Stock	6.22
122	20054536 SCREW $$$	Not Available
123	20060016 PROTECTION COVER	Not Available
124	20054543 SCREW $$$	Not Available
126	20060034 TORSIONAL SPRING	Low Stock	5.25
127	20081529 WORM WHEEL COVER	Not Available
128	20060087 WORM WHEEL COVER FENCE	Not Available
131	F28.0114.0003 ROUND BLOW PIPE-BLACK	Low Stock	12.49
132	F28.0114.0002 ACCESSORY - BLOWER TUBE - FLAT TIP TUBE	On Order	11.99

Manufacturer Model Number	EBP28-1
EAN	5059340256375
Brand	Erbauer
Description	27.6CC BLOWER VACUUM
