GoodHome GHCPO45 BLACK COMPACT MICROWAVE OVEN
Drawing 1 | Item# | Part Details | Availability | £ | |
|---|---|---|---|---|
| Drawing 1 | ||||
| A00 | 12270000032783
CAVITY ASSEMBLY | Not Available | ||
| A01 | 12570000000067
SPLASH COVER (CAN USE AA0000000119) | In Stock | 13.99 | |
| A17-2 | 12270000032656
HINGE ASSEMBLY | In Stock | 14.99 | |
| B01 | 12270000005158
BASE PLATE | Not Available | ||
| C00 | 17270000B72412_1257000000
CONTROL PANEL ASSEMBLY | In Stock | 49.99 | |
| C01 | 12170000001279
CONTROL PANEL | Low Stock | 37.99 | |
| C18 | 17170000003899
TOUCH PCB | In Stock | 22.99 | |
| C18 | 17170000004801
MI ASSEMBLY | In Stock | 25.99 | |
| C18 | 17170000003913
MI ASSEMBLY | In Stock | 29.99 | |
| C34 | 12570000001649
CONTROL PANEL GLASS SILK-SCREEN | In Stock | 22.99 | |
| C50 | 12670000001672
SEALING RING | Low Stock | 19.99 | |
| C56 | 12270000008170
CONTROL PLATE BRACKET | Low Stock | 4.99 | |
| D00 | 12270000B54384_12570000A3
DOOR ASSEMBLY | In Stock | 64.99 | |
| D01 | 12270000026060
DOOR FRAME DROP GLUE ASSEMBLY | Not Available | ||
| D02 | 12270000020237
DOOR LATCH | In Stock | 11.99 | |
| D03 | 12970000000385
SPRING | In Stock | 6.99 | |
| D05 | 12570000000025
HEAT INSULATION GLASS | Low Stock | 19.99 | |
| D06 | 12570000A37998
DOOR GLASS | Low Stock | 19.99 | |
| D07 | 12170000025667
DOOR PANEL | Low Stock | 24.99 | |
| D08 | 12170000020623
DOOR GASKET | In Stock | 19.99 | |
| D14 | 12970000000596
METAL HANDLE | In Stock | 18.99 | |
| D17 | 12170000004514
HANDLE HOLDER | Low Stock | 5.99 | |
| D23 | 12970000000031
DOOR SHAFT | Low Stock | 5.99 | |
| E01 | 17470000000804
MAGNETRON (CAN USE AA0000002571 OR 17470000007203) | In Stock | 34.99 | |
| E05 | 17470000003522
H.V.TRANSFORMER (CAN USE 25106785) | Low Stock | 28.99 | |
| E06 | 17470000000683
H V CAPACITOR (CAN USE AA0000000079) | In Stock | 28.99 | |
| E07 | 17470000001007
H.V.DIODE | In Stock | 18.99 | |
| E10-E11 | 17170000002914
NOISE FLITER ASSEMBLY | In Stock | 14.99 | |
| E13 | 17470000017698
INTEGRATED LAMP | In Stock | 9.99 | |
| E14 | 12270000000202
LAMP COVER | In Stock | 6.99 | |
| E16 | 17470000000121
POWER CORD (WAS 261201003280) | In Stock | 9.99 | |
| E26 | 17170000004580
TEMPERATURE SENSOR | In Stock | 4.99 | |
| E28 | 17470000001561
H.V.FUSE | In Stock | 11.99 | |
| E33 | 17470000001472
THERMOSTAT 160/95 | In Stock | 10.99 | |
| E37 | 17470000009120
THERMOSTAT 150/90 | In Stock | 9.99 | |
| E48 | 17470000001471
THERMOSTAT 180/145 | In Stock | 11.99 | |
| F11 | 12170000003981
BRACKET | Not Available | ||
| F13 | 12270000008213
FIXING BRACKET | Not Available | ||
| G03 | 17470000001044
METAL HEATER UPPER | In Stock | 20.99 | |
| G09 | 12270000032719
HEAT INSULATOR | Not Available | ||
| G10 | 17470000001085
HEATER | In Stock | 20.99 | |
| L03 | 17470000002315
MICROSWITCH INTERLOCK | In Stock | 11.99 | |
| L04 | 17470000008424
MICROSWITCH MONITOR | In Stock | 6.99 | |
| L05 | 17470000011405
MAIN WIRE HARNESS | Low Stock | 19.99 | |
| L09 | 12170000011191
LATCH BOARD | In Stock | 10.99 | |
| L10 | 12170000011190
LATCH BOARD | In Stock | 10.99 | |
| L11 | 12170000007317
INTERLOCK LEVER | In Stock | 10.99 | |
| L14 | 17470000001462
MAIN WIRE HARNESS | Low Stock | 11.99 | |
| R00 | 12270000B68356
CONVECTION ASSEMBLY | In Stock | 34.99 | |
| R10 | 12270000006280
HEAT INSULATOR | Not Available | ||
| R23 | 12270000028956
HEAT INSULATOR ASSEMBLY | Low Stock | 29.99 | |
| R24 | 12270000028957
HEAT INSULATOR ASSEMBLY | Low Stock | 3.99 | |
| R25 | 12270000028958
HEAT INSULATOR ASSEMBLY | Low Stock | 3.99 | |
| R26 | 12470000000012
HEAT INSULATION COTTON | Not Available | ||
| T01 | 11002014000043
TURNTABLE MOTOR (CAN USE 261200300060) | In Stock | 17.99 | |
| T02 | 12570000000020
COUPLER | Low Stock | 10.99 | |
| T06 | 12270000003329
METAL TRAY | Low Stock | 19.99 | |
| W01 | 12270000025637
MOTOR BRACKET | Not Available | ||
| W03 | 11002017000177
FAN MOTOR/ MOTOR CONV. | In Stock | 39.99 | |
| W06 | 12170000000657
WIND GUIDE | Not Available | ||
| W06-A | 12270000025639
AIR DUCT | Low Stock | 4.99 | |
| W06-B | 12270000025638
AIR DUCT | Low Stock | 4.99 | |
| W09-A | 12270000024697
WIND GUIDE | Low Stock | 4.99 | |
| W09-B | 12170000000659
WIND GUIDE | Low Stock | 12.99 | |
| W09-C | 12170000020289
WIND GUIDE | Low Stock | 4.99 | |
| W09-D | 12170000020290
WIND GUIDE | Low Stock | 4.99 | |
| W15 | 12170000020823
WIND GUIDE | Not Available | ||
| W27 | 12270000032717
AIR DUCT | Low Stock | 4.99 | |
| W28 | 12270000008147
UPPER BRACKET | Not Available | ||
| Z01 | 12270000006217
CAPACITOR HOLDER | Not Available | ||
| Z03 | 12170000009426
FILTER BRKT. | In Stock | 4.99 | |
| Z08 | 12170000003919
WIRE BINDER | Not Available | ||
| Z28 | 12270000028936
COVER | Not Available | ||
| Z29 | 12270000B51865
COVER | Not Available | ||
| Z30 | 12270000036308
COVER | Not Available | ||
| Z31 | 12270000000203
METAL COVER | Not Available | ||
| Z36 | 12570000000937
LAMP GLASS | In Stock | 10.99 | |
| Z37 | 12270000008187
LEFT FRONT PLATE BRACKET | Not Available | ||
| Z38 | 12270000005547
RIGHT FRONT PLATE BRACKET | Not Available | ||
| Z39 | 12970000000431
INSTALLATION KIT | In Stock | 10.00 | |
| Z40 | 12170000000070
PAD | Not Available | ||
| Z41 | 12170000007374
SEALING COVER | Not Available | ||
| RACK-1 | 12970000000342
RACK | In Stock | 13.99 | |
| RACK-2 | 12970000000345
RACK | In Stock | 14.99 | |
| Manufacturer Model Number | GHCPO45 |
| EAN | 5059340350882 |
| Brand | GoodHome |
| Description | BLACK COMPACT MICROWAVE OVEN |
