Mac Allister MCI1303LWM LAWN MOWER - 72V - 43CM
Drawing 1 | Item# | Part Details | Availability | £ | |
|---|---|---|---|---|
| Drawing 1 | ||||
| A01 | 1006070001
HANDLE BAR ASSEMBLY | On Order | Contact Us | |
| A02 | 1002424023
KNOB | On Order | Contact Us | |
| 1 | 1057630001
HANDLE GRIP | Not Available | ||
| 2 | 1255831001
UPPER HANDLE BAR | Not Available | ||
| 3 | 1255287001
SAFETY LEVER | Not Available | ||
| 4 | 1005765002
SWITCH BOX ASSEMBLY | On Order | Contact Us | |
| 5 | 1052356001
SWITCH BOX CLAMP | Not Available | ||
| 7 | 1052673001
CABLE CLIP | Not Available | ||
| 8 | 2601029001
THROUGH-BOLT - M8X45 | Not Available | ||
| 9 | 1050409049
KNOB $$$ USE 1002424023 | Not Available | ||
| 10 | 2600127001
NUT $$$ USE 1002424023 | Not Available | ||
| 11 | 1055353001
BAR SLEEVE | Not Available | ||
| 12 | 1255832001
LOWER HANDLE BAR | Not Available | ||
| 13 | 1251011001
HANDLE PIN | Not Available | ||
| 14 | 1350141001
SPRING | Not Available | ||
| 15 | 1200110001
LOCKING SLEEVE | Not Available | ||
| 16 | 2601187001
CYLINDRICAL PIN | Not Available | ||
| 17 | 1051261001
KNOB | On Order | Contact Us | |
| 18 | 1052303001
BATTERY COVER | On Order | Contact Us | |
| 19 | 1057402002
BATTERY HOUSING | Not Available | ||
| 21 | 1005776001
BATTERY TERMINAL | On Order | Contact Us | |
| 23 | 1350217001
SPRING | Not Available | ||
| 24 | 1251563002
HINGE SHAFT | Not Available | ||
| 25 | 1052308001
HINGE | Not Available | ||
| 26 | 1052313001
HINGE PLATE | Not Available | ||
| 27 | 1050218001
CABLE CLAMP | Not Available | ||
| 28 | 1052306003
MOTOR HOUSING COVER (RH) | Not Available | ||
| 29 | 2402322001
CONTROL PCB | On Order | Contact Us | |
| 30 | 1052305004
MOTOR HOUSING COVER (LH) | Not Available | ||
| 31 | 2000071001
FERRITE RING | Not Available | ||
| 32 | 1052304001
MAIN CASING | Not Available | ||
| 34 | 1052307003
MOTOR HOUSING COVER | Not Available | ||
| 35 | 1251564001
WIRE CLIP | Not Available | ||
| 38 | 2402333001
BLDC MOTOR ASSEMBLY | On Order | Contact Us | |
| 39 | 1052318001
MOTOR BASE | Not Available | ||
| 40 | 2601187001
CYLINDRICAL PIN | Not Available | ||
| 42 | 1050992001
REAR DISCHARGE COVER | On Order | Contact Us | |
| 43 | 1350110001
SPRING | Not Available | ||
| 44 | 1050776001
SPRING CAP | Not Available | ||
| 45 | 1255841001
REAR DISCHARGE COVER SHAFT | Not Available | ||
| 46 | 2600709002
C-CLIP | Not Available | ||
| 47 | 1005518003
CHASSIS - 43CM | Not Available | ||
| 48 | 1255834001
HANDLE BRACKET - LH | Not Available | ||
| 49 | 1252171001
THROUGH-BOLT | Not Available | ||
| 54 | 1255835001
HANDLE BRACKET - RH | Not Available | ||
| 55 | 1056631006
HEIGHT ADJUSTMENT HANDLE | Not Available | ||
| 56 | 1004999002
HEIGHT ADJUSTMENT LEVER | Not Available | ||
| 59 | 1255260001
HEIGHT ADJUSTMENT SELECTOR | Not Available | ||
| 61 | 1056633001
ACCESSORY - MULCHING PLUG INSERT | Not Available | ||
| 62 | 1255833001
ACCESSORY - GRASS COLLECTOR FRAME | Not Available | ||
| 63 | 1057629001
ACCESSORY - GRASS COLLECTOR | On Order | Contact Us | |
| 64 | 1253905001
WOODRUFF KEY | Not Available | ||
| 65 | 1006069001
BLADE BACKING PLATE | Not Available | ||
| 66 | 1255837001
ACCESSORY - BLADE - 43CM | On Order | Contact Us | |
| 67 | 1251439001
BLADE WASHER | On Order | Contact Us | |
| 68 | 1250909001
BLADE RETAINING BOLT (3/8-24UNF) | On Order | Contact Us | |
| 69 | 1005517001
REAR AXLE ASSEMBLY | On Order | Contact Us | |
| 70 | 1050642001
SHAFT BUSHING | Not Available | ||
| 71 | 1250469001
SPRING HOOK | Not Available | ||
| 72 | 1200007001
SHAFT SLEEVE | Not Available | ||
| 73 | 1056247000
WHEEL - 20CM | On Order | Contact Us | |
| 75 | 1052418016
WHEEL TRIM - 20CM | On Order | Contact Us | |
| 76 | 1350589001
SPRING | Not Available | ||
| 77 | 1255543001
HEIGHT ADJUSTMENT LINK ROD | Not Available | ||
| 79 | 1005516001
FRONT AXLE ASSEMBLY | On Order | Contact Us | |
| 80 | 1056240000
WHEEL - 165MM | On Order | Contact Us | |
| 81 | 1052417016
WHEEL TRIM - 165MM | On Order | Contact Us | |
| Manufacturer Model Number | MCI1303LWM |
| EAN | 5063022749000 |
| Brand | Mac Allister |
| Description | LAWN MOWER - 72V - 43CM |
