Performance Power PPT1186LWM LAWN MOWER - 36V - 38CM (2x18V)
Drawing 1 | Item# | Part Details | Availability | £ | |
|---|---|---|---|---|
| Drawing 1 | ||||
| 1 | 8.64.0586
SWITCH CONTROL CABLE | Not Available | ||
| 2 | 8.41.5875-B
SWITCH BOX UPPER COVER | Low Stock | 4.99 | |
| 3 | 8.41.5175-P123U
SWITCH BOX - BUTTON | Not Available | ||
| 4 | 8.34.0550
SPRING | Low Stock | 1.99 | |
| 5 | 8.83.0175
SWITCH | Low Stock | 4.99 | |
| 6 | 8.41.5275-P123U
SWITCH BOX - ROCKER | Not Available | ||
| 7 | 5.51.1001
SCREW | Not Available | ||
| 8 | 8.34.0475
SWITCH TRIGGER SPRING | Not Available | ||
| 9 | 8.41.5775-B
SWITCH BOX BASE | Low Stock | 3.99 | |
| 10 | 5.51.0101
SCREW $$$ | Not Available | ||
| 11 | 8.41.5075-B
SWITCH BOX COVER | Low Stock | 4.99 | |
| 12 | 5.51.0201
SCREW | Not Available | ||
| 13 | 8.43.0375
SOFT GRIP | Low Stock | 4.99 | |
| 14 | 7.33.0475-3B
SWITCH LEVER | Not Available | ||
| 15 | 8.41.2175-B
SWITCH LEVER LEFT SUPPORT BRACKET | Low Stock | 4.99 | |
| 16 | 8.41.2275-B
SWITCH LEVER RIGHT SUPPORT BRACKET | Low Stock | 4.99 | |
| 17 | 8.33.0479-B
UPPER HANDLE BAR | Not Available | ||
| 18 | 8.41.1279-B
END CAP | Not Available | ||
| 19 | 5.51.0609
BOLT | Not Available | ||
| 20 | 8.41.4375-B
WIRE SLOT | Not Available | ||
| 21 | 8.33.0998-B
LOWER HANDLE BAR | Not Available | ||
| 23 | 7.41.2461-5P123U
LOCKING KNOB | Not Available | ||
| 24 | 8.41.1753-B
GRASS COLLECTOR - HANDLE | Not Available | ||
| 25 | 8.41.0681-P123U
GRASS COLLECTOR - FILL INDICATOR | Not Available | ||
| 26 | 8.41.0798-B
GRASS COLLECTOR - LID | Not Available | ||
| 27 | 8.44.0198
GRASS COLLECTOR - BASE | Not Available | ||
| 28 | 8.33.0898-B
GRASS COLLECTOR - FRAME | Not Available | ||
| 29 | 5.51.0402
GRASS COLLECTOR SCREW | Not Available | ||
| 30 | 8.41.1578-P123U
REAR WHEEL TRIM | Not Available | ||
| 32 | 8.41.1178-B
REAR WHEEL - 200MM | Not Available | ||
| 33 | 5.53.2185
FLAT WASHER | Not Available | ||
| 34 | 8.33.1298
REAR AXLE | Not Available | ||
| 35 | 8.41.1478-P123U
FRONT WHEEL TRIM | Not Available | ||
| 36 | 8.41.1078-B
FRONT WHEEL - 140MM | Not Available | ||
| 38 | 8.33.1198
FRONT AXLE | Not Available | ||
| 41 | 8.33.0698-1
ACCESSORY - LAWN MOWER BLADE - 38CM | Not Available | ||
| 42 | 8.41.1098-N
BLADE BACKING FLANGE | Not Available | ||
| 44 | 8.29.0175
FRONT BALLAST | Not Available | ||
| 48 | 8.33.0550
AXLE PRESSURE PLATE | Low Stock | 4.99 | |
| 50 | 8.33.1075
AXLE BAFFLE | Low Stock | 4.99 | |
| 51 | 5.51.0502
SCREW $$$ | Not Available | ||
| 52 | 8.41.0398-B
REAR DISCHARGE CHUTE | Not Available | ||
| 54 | 5.51.1411
THROUGH-BOLT - M8X40 | Not Available | ||
| 55 | 8.41.0598-P123U
LOCKING KNOB | Not Available | ||
| 56 | 5.52.0198
NUT - M8 | Not Available | ||
| 57 | 8.41.5375-N
CRIMPING PLATE | Not Available | ||
| 59 | 8.41.3286
CONTROLLER BRACKET | Low Stock | 12.99 | |
| 60 | 5.51.0601
SCREW | Not Available | ||
| 61 | 8.62.0186-1
CONTROL PCB ASSEMBLY | Not Available | ||
| 63 | 7.12.0698
BLDC MOTOR ASSEMBLY | Not Available | ||
| 64 | 8.41.2986-N
MOTOR BASE PLATE | Not Available | ||
| 65 | 5.51.1003
SCREW | Not Available | ||
| 69 | 8.35.0386
GEARBOX | Not Available | ||
| 70 | 8.41.3586
GEARBOX WASHER | Not Available | ||
| 71 | 5.55.0799
WOODRUFF KEY | Not Available | ||
| 72 | 5.54.0201
BEARING | Low Stock | 7.83 | |
| 73 | 8.32.0286B
GEARBOX OUTPUT SHAFT | Not Available | ||
| 74 | 8.41.3086-N
GEARBOX COVER | Not Available | ||
| 75 | 5.51.0161
SCREW | Not Available | ||
| 77 | 8.33.0875
REAR AXLE | Low Stock | 9.99 | |
| 78 | 8.34.0186
HEIGHT ADJUSTMENT SPRING | Not Available | ||
| 79 | 8.34.0486
FRONT AXLE SPRING | Not Available | ||
| 80 | 8.33.0398
HEIGHT ADJUSTMENT LINK-ROD (FRONT) | Not Available | ||
| 81 | 8.33.0498
HEIGHT ADJUSTMENT LINK-ROD (REAR) | Not Available | ||
| 82 | 8.33.0586
HEIGHT ADJUSMENT LEVER | Not Available | ||
| 83 | 8.41.1486-N
HEIGHT ADJUSTMENT LINKAGE | Not Available | ||
| 85 | 5.51.2201
CROSS RECESSED PAN HEAD TAPPING SCREWS | Not Available | ||
| 86 | 8.41.1181-P123U
HEIGHT ADJUSTMENT HANDLE | Not Available | ||
| 87 | 5.52.0103
NUT | Not Available | ||
| 89 | 8.41.0298-P7484C
UPPER COVER | Not Available | ||
| 90 | 8.41.1186-B
HEIGHT ADJUSTMENT SELECTOR PLATE | Not Available | ||
| 91 | 8.33.0686
HEIGHT ADJUSTMENT GAITER | Not Available | ||
| 93 | 8.41.0786-B
UPPER HANDLE | Not Available | ||
| 94 | 8.34.0198
SPRING | Not Available | ||
| 95 | 8.41.0698-P7484C
REAR DISCHARGE CHUTE COVER | Not Available | ||
| 96 | 8.41.4486-B
BATTERY HOUSING (RH) | Not Available | ||
| 97 | 8.45.0379
SECURITY KEY LANYARD | Not Available | ||
| 98 | 8.41.0671-P123U
SECURITY KEY HOLDER | Not Available | ||
| 99 | 7.41.0771-5P123U
ACCESSORY - SECURITY KEY - PERFORMANCE POWER | Not Available | ||
| 100 | 8.41.2386-B
BATTERY COVER SUPPORT LUG (RH) | Not Available | ||
| 101 | 8.41.2486-B
BATTERY COMPARTMENT HOOK | Not Available | ||
| 102 | 8.41.1986-C10
BATTERY COVER | Not Available | ||
| 103 | 8.41.2286-B
BATTERY COVER SUPPORT LUG (LH) | Not Available | ||
| 104 | 5.51.0802
SCREW $$$ | Not Available | ||
| 105 | 8.41.4786-B
GUIDE RAIL COVER FOR BATTERY) | Not Available | ||
| 106 | 8.69.0199
20k RESISTOR | Not Available | ||
| 107 | 8.41.4586-B
BATTERY HOUSING (LH) | Not Available | ||
| 108 | 7.41.1492-5B
BATTERY SOCKET | Not Available | ||
| 109 | 8.41.4686-B
BATTERY GUIDE | Not Available | ||
| 110 | 8.41.3186-B
BATTERY COVER SUPPORT LUG SHAFT | Not Available | ||
| 111 | 8.34.0686
BATTERY COVER SUPPORT LUG SPRING | Not Available | ||
| 112 | 8.64.0286
BATTERY COMPARTMENT WIRING HARNESS | Not Available | ||
| 113 | 8.64.0386
BATTERY COMPARTMENT WIRING HARNESS | Not Available | ||
| 114 | 8.64.0486
CONTROL PCB WIRING HARNESS | Not Available | ||
| 115 | 8.14.0292-1
BATTERY - PP | Not Available | ||
| 116 | 8.67.0492-1
CHARGER - PP | Not Available | ||
| Manufacturer Model Number | PPT1186LWM |
| EAN | 5063022637352 |
| Brand | Performance Power |
| Description | LAWN MOWER - 36V - 38CM (2x18V) |
