Titan TTI1142LWM LAWN MOWER - 18V - 32CM
Drawing 1 | Item# | Part Details | Availability | £ | |
|---|---|---|---|---|
| Drawing 1 | ||||
| SWITCH-BOX | 1005604002
SWITCH BOX ASSEMBLY (TITAN) (ALT GP0000007385) | Not Available | ||
| 1 | 2600532000
SCREW $$$ | Not Available | ||
| 2 | 2601330000
SCREW $$$ | Not Available | ||
| 3 | 1057164000
BATTERY COMPARTMENT | Low Stock | 3.99 | |
| 4 | 1350617000
SPRING | Not Available | ||
| 5 | 1057213000
SLIDER | Not Available | ||
| 6 | 2600502000
SCREW $$$ | Not Available | ||
| 7 | 2600532000
SCREW $$$ | Not Available | ||
| 8 | 1350347000
TENSION SPRING | Not Available | ||
| 9 | 2600533000
SCREW $$$ | Not Available | ||
| 10 | 1057214000
HINGE PIN | Not Available | ||
| 11 | 1057165000
HINGE ARM | Not Available | ||
| 12 | 1057157001
MOTOR HOUSING - UPPER | Not Available | ||
| 13 | 2600533000
SCREW $$$ | Not Available | ||
| 14 | 1057159001
BATTERY COMPARTMENT COVER | Low Stock | 3.99 | |
| 15 | 1057215001
BUTTON | Not Available | ||
| 16 | 1350618000
BUTTON SPRING | Not Available | ||
| 17 | 1057408000
SWITCH BOX COVER - UPPER | Not Available | ||
| 18 | 2600532000
SCREW $$$ | Not Available | ||
| 19 | 1057407000
CABLE CLAMP | Not Available | ||
| 20 | 2402209000
SWITCH | Not Available | ||
| 21 | 1057219000
LEVER | Not Available | ||
| 22 | 1057237000
HANDLEBAR PADDING | Not Available | ||
| 23 | 2600538000
SCREW $$$ | Not Available | ||
| 24 | 2700202000
SCREW $$$ | Not Available | ||
| 25 | 1057220000
SWITCH BOX COVER - LOWER | Not Available | ||
| 26 | 1255643001
HANDLEBAR - UPPER | Not Available | ||
| 27 | 1056310006
GRASS COLLECTOR - HANDLE | Low Stock | 5.99 | |
| 28 | 1056311006
GRASS COLLECTOR - FILL INDICATOR | Low Stock | 0.99 | |
| 29 | 1056312000
GRASS COLLECTOR - LID SECTION | In Stock | 3.99 | |
| 30 | 1254920000
GRASS COLLECTOR - FRONT FRAME | Low Stock | 3.99 | |
| 31 | 1254972000
GRASS COLLECTOR - WASHER | Not Available | ||
| 32 | 2600532000
SCREW $$$ | Not Available | ||
| 33 | 1057238001
GRASS COLLECTOR - MESH BASE | Low Stock | 9.99 | |
| 34 | 1055480003
LOCKING KNOB - M6 | In Stock | 0.50 | |
| 35 | 2600008000
STEP BOLT - M6X45 | In Stock | 0.50 | |
| 36 | 1255576000
HANDLEBAR - LOWER (SET) | Low Stock | 2.99 | |
| 37 | 1055812000
CABLE CLIP | Low Stock | 0.50 | |
| 38 | 2402232000
SWITCH HARNESS | Not Available | ||
| 39 | 2600533000
SCREW $$$ | Not Available | ||
| 40 | 2402234000
MOTOR - 18V | In Stock | 44.99 | |
| 41 | 2600769000
BEARING | Not Available | ||
| 42 | 1255639000
PINION GEAR | Not Available | ||
| 43 | 1255638000
DRIVE GEAR | Not Available | ||
| 44 | 1057346000
MOTOR HOUSING - LOWER | Not Available | ||
| 45 | 1255579000
OUTPUT SHAFT | Not Available | ||
| 46 | 2600797000
BEARING | Not Available | ||
| 47 | 1052475000
BACKING FLANGE | Low Stock | 0.50 | |
| 48 | 2600546000
SCREW $$$ | Not Available | ||
| 49 | 2402231000
CONTROL PCB ASSEMBLY | In Stock | 34.99 | |
| 50 | 2600532000
SCREW $$$ | Not Available | ||
| 51 | 1057407000
CABLE CLAMP | Not Available | ||
| 52 | 1057229000
REAR CHUTE HINGE CLIP | Low Stock | 0.50 | |
| 53 | 1050052000
REAR CHUTE COVER | Low Stock | 1.49 | |
| 54 | 1350557000
RETURN SPRING | Low Stock | 0.99 | |
| 55 | 1057230000
HINGE PIN | Not Available | ||
| 56 | 1255572000
REAR AXLE | Low Stock | 2.99 | |
| 57 | 1056318000
REAR AXLE PIVOT BRACKET - LEFT | Low Stock | 1.49 | |
| 58 | 1055473000
WHEEL - 165MM | In Stock | 2.99 | |
| 59 | 1255578000
RETAINING RING | Not Available | ||
| 60 | 1057163000
WHEEL - DECOR RING - 165MM | Low Stock | 0.50 | |
| 61 | 1057162000
WHEEL - TRIM COVER - 165MM | Low Stock | 0.99 | |
| 62 | 1057236000
PROTECTIVE FILTER | Not Available | ||
| 63 | 1057231000
VENTILATION PLATE | Not Available | ||
| 64 | 1350555000
TENSION SPRING | Not Available | ||
| 65 | 1056319000
HEIGHT ADJUSTMENT LINK ROD | Low Stock | 2.99 | |
| 66 | 2601479000
SCREW $$$ | Not Available | ||
| 67 | 2600533000
SCREW $$$ | Not Available | ||
| 68 | 1057232000
FRONT TRIM | Not Available | ||
| 69 | 2601220000
BLADE BOLT - M8X20 | Not Available | ||
| 70 | 1255574000
ACCESSORY - BLADE - CY32D - 32CM | In Stock | 4.99 | |
| 71 | 1056309005
HEIGHT ADJUSTMENT LEVER | Not Available | ||
| 72 | 1056317005
FRONT AXLE PIVOT BRACKET - LEFT | Not Available | ||
| 73 | 1350556000
HEIGHT ADJUSTMENT TORSION SPRING | Not Available | ||
| 74 | 2600549000
SCREW $$$ | Not Available | ||
| 75 | 1254921000
HEIGHT ADJUSTMENT HANDLE SHAFT | Low Stock | 0.99 | |
| 76 | 1255573000
FRONT AXLE | Not Available | ||
| 77 | 1056323005
COMB - LEFT | Not Available | ||
| 78 | 2600533000
SCREW $$$ | Not Available | ||
| 79 | 1057233002
CHASSIS | Not Available | ||
| 80 | 1056324005
COMB - RIGHT | Not Available | ||
| 81 | 1056315000
FRONT AXLE PIVOT BRACKET - RIGHT | Low Stock | 0.99 | |
| 82 | 1055476000
WHEEL - 140MM | In Stock | 4.99 | |
| 83 | 1057161001
WHEEL - DECOR RING - 140MM | Low Stock | 0.50 | |
| 84 | 1057160000
WHEEL - TRIM COVER - 140MM | Low Stock | 0.99 | |
| 85 | 1057234004
FRONT COVER | Not Available | ||
| 86 | 1056316000
REAR AXLE PIVOT BRACKET - RIGHT | Low Stock | 0.99 | |
| 87 | 2600491000
SCREW $$$ | Not Available | ||
| 88 | 1057318000
BALLAST PACK | Not Available | ||
| 89 | MFC18
CHARGER - 4.0AH 18V - FAST CHARGE - MFC18 | In Stock | 29.99 | |
| 90 | MBAT18-5
BATTERY - 18V 5000MAH - MBAT18-5 (ALT TTI803BAT) | Not Available | ||
| Manufacturer Model Number | TTI1142LWM |
| EAN | 5063022591135 |
| Brand | Titan |
| Description | LAWN MOWER - 18V - 32CM |
